Butt Hinges

The H hinge is so called because of its resemblance to the letter H.

The hinge is made from solid brass and finished with a clear lacquer.

Dimensions:

Small:
Total Length - approx. 51mm (2")
Total Width - approx. 32mm (15/16")
Width of section - approx. 12mm (1/2")
Closed Width - approx. 19mm (13/16")

Large:
Total Length - approx. 64mm (29/16")
Total Width - approx. 36mm (17/16")
Width of section - approx. 13mm (9/16")
Closed Width - approx. 21mm (7/8")

A solid brass butt hinge, the thickness of the brass is 2mm

Dimensions -

Length - approx. 102mm (41/16")
Width - approx. 60mm (27/16")
Closed Width - approx. 34mm (13/8")

A solid brass butt hinge, the thickness of the brass is 3mm

Dimensions -

Length - approx. 102mm (41/16")
Width - approx. 67mm (211/16")
Closed Width - approx. 39mm (19/16")

A solid brass aluminium hinge, the thickness is 2mm

Dimensions -

Length - approx. 101mm (41/16")
Width - approx. 72mm (215/16")
Closed Width - approx. 41mm (111/16")

A solid brass butt hinge, the thickness of the brass is approx. 1mm

Dimensions -

Length - approx. 63mm ()
Width - approx. 34mm ()
Closed Width - approx. 19mm ()

This hinge is made of solid brass, finished with a clear lacquer. The thickness is approx. 1mm

Dimensions -

Height - approx. 51mm (2")
Width - approx. 26mm (1")
Closed Width - approx. 16mm (11/16")

This solid brass butt hinge is finished with a clear lacquer. The thickness of the brass is

Dimensions -

Height - approx. 38mm (19/16")
Width - approx. 20mm (13/16")
Closed Width - approx. 12mm (1/2")

A solid brass butt hinge, finished in a clear polished lacquer. The brass is approx. 2mm thick.

Dimensions -

Height - approx. 76mm (3")
Width - approx. 50mm (2")
Closed Width - approx. 29mm (13/16")

Available in 2 sizes - Small & Large. Borth are made from Brass Effect

Dimensions:Approx
Small
Height 42mm (111/16")
Width - 34mm (13/8")
Projection - 19mm (13/16")

Large
Height - 51mm (2")
Width - 40mm (15/8")
Projection - 23mm (15/16")

The washered butt hinge comes is 2 finishes; Brass and Polished Brass

Dimensions:
Total Width - approx. 65mm (25/8")
Length - approx. 102mm (41/16")
Closed Width - approx. 39mm (19/16")
